English–DPI620G Instruction Manual | 47
Process Options
Figure 3-20: Relief Valve Utility
3.6 Process Options
Process options are related to the measured values for identified channel functions. Options
available are related to the function and include:
Option Description
Tare Used to set a temporary value for zero. This makes an adjustment to all
subsequent readings on the display
Alarm Shows when a limit has been exceeded
Filter Sets the Band and Time Constant for a low-pass filter
Flow When selected, the square root of the measured value is shown.
Scaling Absolute values are scaled.
Rising
Falling
