EMC VNX VG2/VG8 Gateway Configuration Setup Guide
232
Manually Zone Switches and Configure System LUNs
EMC CONFIDENTIAL
Zone the FC/FCoE switches by WWN
Manually zoning the FC/FCoE switches by using the World Wide Name (WWN)
involves several steps. You must first collect the WWNs from the blades and the
backend. You then use the WWNs to zone the switch.
Note: If you are zoning a Cisco FCoE switch, configure the switch parameter “no errdisable
detect cause all” for optimal performance.
Collecting blade
WWNs
Note: If your VG2/VG8 system is using a Symmetrix backend for the boot array, and the
switch is already zoned, and the hypervolumes for the system LUNs already exist, go to
“Return to File OE installation” on page 250.
If you were instructed to manually configure the FC/FCoE switches during File OE
installatioin, the installation program displays the WWN of each FC/FCoE HBA port
on each Data Mover (see examples below). A reminder to configure switch zoning
and storage groups also appears.
Record the WWNs for the next steps. To avoid mistakes, copy and paste the WWNs to
a text file.
Note: These values are the WWNs of the Data Mover ports, not the array ports.
The following is an FC example of the WWNs displayed:
Setup Fibre Switch Zoning based on Word Wide Names Zoning specification and Setup Storage
Groups and Control LUNs on the backend with the
following HBA UIDs. Please see the Installation Guide for help.
Data Mover 2 WWN Node/Port Names:
FCP HBA 0: N_PORT S_ID 6a1413 Node 5006016090602d0b Port 5006016010602d0b
FCP HBA 1: N_PORT S_ID 6a1513 Node 5006016090602d0b Port 5006016110602d0b
Data Mover 3 WWN Node/Port Names:
FCP HBA 0: N_PORT S_ID 6a1213 Node 5006016090602d0b Port 5006016810602d0b
FCP HBA 1: N_PORT S_ID 6a1313 Node 5006016090602d0b Port 5006016910602d0b
...
The following is an FCoE example of the WWNs displayed:
Data Mover 2 WWN Node/Port Names:
FCoE HBA 0: N_PORT S_ID 20002d Node 5006016044601c42 Port 5006016044601c42
FCoE HBA 1: N_PORT S_ID 20002e Node 5006016144601c42 Port 5006016144601c42
Data Mover 3 WWN Node/Port Names:
FCoE HBA 0: N_PORT S_ID 200029 Node 5006016844601c42 Port 5006016844601c42
FCoE HBA 1: N_PORT S_ID 200025 Node 5006016944601c42 Port 5006016944601c42
Note: Do not press C to continue on the Control Station session yet.
