Create control LUNs on VNX array
239
Manually Zone Switches and Configure System LUNs
EMC CONFIDENTIAL
Create RAID group
for control LUNs
The VNX gateway system requires six LUNs for software and system data files. You
will create control LUNs on four unused disks. If you are adding the VNX gateway
system to an existing array that does not have unused disks, add disks or rearrange
existing LUNs to free up the disks.
To create control LUNs, first create a RAID group for the control LUNs by using one
of the following methods:
◆ “Unisphere” on page 239
◆ “Navisphere CLI” on page 239
Unisphere If you are using Unisphere, create a RAID group by following these steps:
1. From the main Unisphere page, select the storage array.
2. Select Storage > Storage Pools, then click the RAID groups tab.
3. Click the Create button. The Create Storage Pool dialog box appears.
4. Under the General tab, click the RAID Group radio button.
5. Create a new RAID group by using the settings in Table 9:
6. Click Apply.
Navisphere CLI If you are using Navisphere CLI to create a RAID group, enter the following
command:
Note: This example uses RAID group 0 and disks 0 through 3 on the first DAE. You can use any
RAID group ID and any four disks.
# navicli -h <SP_A_IP_address> createrg 0 0_0_0 0_0_1 0_0_2 0_0_3
Table 9 Create RAID group settings
General tab field Value to enter Advanced tab field Value to enter
Storage Pool ID Select first available value. Automatically delete after last
LUN is deleted
Uncheck this checkbox.
RAID Type Select RAID5. Expansion and Defragmentation
Priority
Medium
Number of Disks 4 ——
Disks Manual, then click Select
to manually select disks
——
