User chart control •
••
• 271
Point report
Points are shown as symbol and they are very important element of a user chart. Point is a center point for subchart
inside an user chart. Subcharts are small enough to be sent for radar screen.
User chart’s Point report is generated by the system. This report appears on display, when user press User Chart
pushbutton and select Point report command from the menu.
In order to print this report do follow:
1. From File menu select Print.
2. Report is now print automatically to default printer.
If printed area is too wide for page layout, you can change size and/or type of font:
1. From Edit menu select Set font…
2. Font dialog appears. Select desired options and press OK. (Recommended font is Fixedsys
and size of font is 9).
To close this report select from File menu Exit. Notepad will be closed.
