• Backup Operations
Read from planning or navigation station
If there is separate planning station connected to system, it is possible to read files from planning station to
navigation station and vice versa.
1. From Control Panel select desired pushbutton.
2. From menu select Backup and Restore command.
3. Select backup drive in Backup device -field.
4. In the Backup Device -field select desired file.
5. Press Restore button in Backup Device -field. If Overwrite existing files is selected the file
with the same name in the ECDIS is replaced with restored file.
How to load chart and route files in the old Vector
system format
The Route and User Chart files can read in Vector System format (Inc). When loading files in Inc format the
ECDIS converts file to format used with the ECDIS. To do it, proceed as follows
1. From Control Panel select desired pushbutton.
2. From menu select Backup and Restore command.
3. Select backup drive in Backup device -field.
4. In the Backup Device -field select desired file.
5. Press Restore button in Backup Device -field.
How to save chart and route files in the old Vector
system format
The Route and User Chart files can write in Vector System format (Inc). When moving files from the ECDIS to
Backup Device the ECDIS converts file to Inc format. To do it, proceed as follows
1. From Control Panel select desired pushbutton.
2. From menu select Backup and Restore command. There will appear Backup & Restore
dialog box in the Dialog box area.
3. In the Hard disk -field select desired file and select Backup file format as Inc.
4. Select backup drive in Backup device -field. Press Backup button in Hard Disk -field.
