• Navigation Tasks

Monitoring

Monitoring is a continuous check of navigation data, user actions and performance of the system.

Part of the monitoring is also the display of electronic sea chart and conning information.

Monitoring

Data

logging

Man over

board

Data

distribution

Alarms

Electronic

sea

chart

Display of electronic sea chart

• Own ship position

• Planned track

• Planned safety lines

• Ship´s predictor

• Chart alarms

• ARPA targets

• Chart information

Alarms

• Route monitoring alarms

• Position calculation alarms

• Position monitoring alarms

• Waypoint approach alarms

• Alarms for sensor failure

• Alarms for system failure
