GE MEDICAL SYSTEMS LOGIQ 400 SERVICE MANUAL

2127661
RENEWAL PARTS
6–70
REV 9
6–2–1 Monitor Assy (FRU No. 100)
Time Required
0.25 Hours
Tool Required
Screwdriver
Hexagonal Wrench
Procedure
WARNING!
PERSONAL INJURY HAZARD. THE NECK ASSY IS SPRING LOADED. RELEASING ARM
WHEN MONITOR IS NOT INSTALLED WILL CAUSE SUDDEN UPWARD MOVEMENT. KEEP
YOUR HEAD AND BODY AWAY FROM ABOVE NECK ASSY.
Refer to ILLUSTRATION 6–14.
1. Turn OFF the system.
2. Remove the CRT Filter. Refer to 6–2–6 on page 6–79.
3. Unscrew four hexagonal screws (
1
–
4
) located beneath the horizontal part of the Neck Assy.
4. Remove the cover located at the bottom of the Neck Assy.
5. Unscrew two screws (
5
and
6
) and remove the plate fixing the cables.
6. Disconnect the four connectors (
7
–
10
).
7. Remove the screw cap located at position (
11
).
8. Loosen one screw (
11
) and pull the Monitor Assy upwards.
Note
When replacing the monitor with the new Monitor Assy (2162081), be sure to attach the proper label
included with the Monitor Assy on to the Escutcheon. To attach the new label, refer to the procedures
in section 6–2–2 on page 6–72.
Note
The color of the Escutcheon for LOGIQ 400CL is different from the other color monitor assy. Use the
proper FRU when replacing the monitor assy for the LOGIQ 400CL.
