GE MEDICAL SYSTEMS
LOGIQ 400 SERVICE
MANUAL
2127661
RENEW
AL P
ARTS
6–1
17
REV 9
6–2–27
Neck Grip (FRU No. 203)
Time Required
5 Minutes
T
ool Required
Hexagonal Wrench
Procedure
Refer to ILLUSTRA
TION 6–49.
1.
T
urn OFF the system.
2.
Loosen two hexagonal screws (
1
and
2
).
3.
Remove the Neck Grip.
NECK GRIP DISASSEMBL
Y
ILLUSTRA
TION 6–49
246
