GE MEDICAL SYSTEMS LOGIQ 400 SERVICE MANUAL
2127661
RENEWAL PARTS
6–100
REV 9
6–2–18 CRT Assy NTSC (FRU No. 158), CRT Assy PAL (FRU No. 159)
Time Required
0.5 Hours
Tool Required
Screwdriver
Procedure
WARNING!
PERSONAL INJURY HAZARD. THE NECK ASSY IS SPRING LOADED. RELEASING ARM
WHEN MONITOR IS NOT INSTALLED WILL CAUSE SUDDEN UPWARD MOVEMENT. KEEP
YOUR HEAD AND BODY AWAY FROM ABOVE NECK ASSY.
Refer to ILLUSTRATION 6–37 on page 6–101.
1. Turn OFF the system.
2. Remove the Monitor Assy NTSC/PAL (FRU 150/151). Refer to 6–2–12 on page 6–90.
3. Remove the Monitor Bottom Assy (FRU 157). Refer to 6–2–17 on page 6–98.
4. Remove the Monitor Cover (FRU 152). Refer to 6–2–13 on page 6–92.
5. Remove the Escutcheon Assy (FRU 153). Refer to 6–2–14 on page 6–93.
6. Remove the CRT Cable Set (FRU 160). Refer to 6–2–19 on page 6–102.
To Next Page
