GE MEDICAL SYSTEMS
2127661
LOGIQ 400 SERVICE MANUAL
RENEWAL PARTS
6–208
REV 9
6–2–83 Nest Mother Assy (FRU No. 615)
Time Required
2 Hours
Tool Required
Screwdriver
Hexagonal Wrench
Procedure
Refer to ILLUSTRATION 6–118 on page 6–209.
1. Turn OFF the system.
2. Remove the Side Cover Left (FRU 301). Refer to 6–2–31 on page 6–127.
3. Remove the Front Base Cover (FRU 305). Refer to 6–2–35 on page 6–131.
4. Remove the Side Cover Right (FRU 302). Refer to 6–2–32 on page 6–128.
5. Remove the Rear Cover (FRU 303). Refer to 6–2–33 on page 6–129.
6. Remove the Front Cover (FRU 306). Refer to 6–2–36 on page 6–132.
7. Remove the Top Cover (FRU 308). Refer to 6–2–38 on page 6–135.
8. Unscrew five Nest Cover screws.
9. Remove the Nest Cover.
10. Remove all the P.C. Boards. Refer to 6–2–78 on page 6–198.
11. Remove the Rear CONN Panel Assy (FRU 501). Refer to 6–2–61 on page 6–166.
12. Remove the HDD LED Assy (FRU 526). Refer to 6–2–76 on page 6–196.
13. Remove the Power Switch Assy (FRU 527). Refer to 6–2–77 on page 6–197.
14. Remove the Probe CONN Set Assy (FRU 512/513). Refer to 6–2–68 on page 6–176.
15. Remove the Nest Fan Assy (FRU 511). Refer to 6–2–67 on page 6–174.
16. Remove the Neck Assy (FRU 201/202). Refer to 6–2–26 on page 6–114.
17. Disconnect thirteen connectors connected with the mother board.
