GE LOGIQ 400 Service Manual

GE MEDICAL SYSTEMS
2127661
LOGIQ 400 SERVICE MANUAL

RENEWAL PARTS
6–251
REV 9
6–4 SYSTEM SOFTWARE INSTALLATION
CAUTION
Software MO (Magneto Optical) disk is not available in Europe. Please replace the hard disk
for European systems instead of installing system software.
GEMS–AM recommends replacement of the HDD assy with the system software installed. Re-
fer to the spare parts section of the service manual to identify the correct HDD assy with the
correct version of software loaded.
6–4–1 Introduction
This section describes the procedures for installing the system software into the hard disk on LOGIQ 400.
Note
You can upgrade the version of LOGIQ 400 system software up using the Software Version Up
function of LOGIQ 400 Service Software. Refer to LOGIQ 400 Proprietary Manual, 2127662.
Note
If you upgrade the system version, it is not necessary to backup the user data before installing new
software. Because the user data remains unchanged after upgrading the system. If you install the
system software a damaged hard disk, it is impossible to backup the user data before installation.
Therefore, it is recommended to backup the user data periodically.
Tool Required
Standard service tool
Laptop PC with terminal emulation
RS232C serial interface cable (cross type)
System software MO disk
Backup user data (MO disk)
Note
Refer to the following example or the pin assignment of Service port described in Chapter 3 and use
the appropriate interface cable.
In the case of 9–pin to 25–pin interface cable:
Service Port of LOGIQ 400 :
Pin No.
Signal
2 TXD
3 RXD
4RTS
5 CTS
7 GND
Serial Port of Your PC :
Pin No. Signal
2 RXD
3 TXD
8 CTS
7RTS
5 GND
