GE MEDICAL SYSTEMS
2127661
LOGIQ 400 SERVICE MANUAL
TM
8–52 OPTIONS
REV 5
8–5 ECG OPTION INSTALLATION
8–5–1 Foreword
This section describes the installation of the ECG option for LOGIQ 400.
8–5–2 Tools Required
Standard field Service Tool kit
8–5–3 Time Required
Approx. 1 Hour
8–5–4 Parts Required
ITEM PART NAME QTY PART # REMARKS
1. ECG Assy 1 P9522WY
ECG Board Assy 1 P9522WZ includes screws for mounting on console
or ECG Board2 Assy 1 2207806 ECG Board Assy (P9522WZ) can be
replaced with ECG Board2 Assy
(2207806)
CONN Panel Assy 1 P9522XB
Caution Label 1 P9524PS
Option Label 1
2. ECG Cable Assy 1 P9509KG For Japan
ECG Cable (system side) 1 P9509KC
ECG Cable (patient side) 1 P9509KD
2. ECG Cable Assy 1 P9509KH For USA, Europe and others
ECG Cable (system side) 1 P9509KE
ECG Cable (patient side) 1 P9509KF
3. PCG sensor 1 P9509KN
8–5–5 Functional Check–out
READ and UNDERSTAND these instructions thoroughly before proceeding with the installation. Perform each step in
sequence and check it off when completed. If a problem occurs after completion, go back through the procedure and
check for implementation errors before contacting your Ultrasound Region Engineer.
CAUTION
Possible operational damage. Failure to strictly follow ESD (Electrostatic Discharge) precau-
tions during this upgrade may cause constant or intermittent operational abnormalities.
Strictly follow all precautions.
Check each step as it is completed.
Perform functional checks to verify that the system is functioning properly. Refer to Chapter 4, Functional Checks.
To Next Page
