GE MEDICAL SYSTEMS
2127661
LOGIQ 400 SERVICE MANUAL
RENEWAL PARTS
6–184
REV 9
6–2–73 MODD (FRU No. 520), MODD Fan (FRU No. 521), MODD Holder Assy (FRU No. 522)
Time Required
30 Minutes
Tool Required
Screwdriver
Procedure
Refer to ILLUSTRATION 6–99 on page 6–185.
1. Turn OFF the system.
2. Remove the Keyboard Panel Assy (FRU 400). Refer to 6–2–49 on page 6–147.
3. Disconnect the MODD Fan Power Cable.
4. Unscrew two screws (
1
and
2
).
5. Remove the MODD Fan Assy
6. Remove the HDDB Assy (FRU 525). Refer to 6–2–75 on page 6–195.
7. Unscrew four screws (
3
6
).
8. Remove the upper metal plate.
9. Disconnect the SCSI Cable and MODD Power Cable.
10. Remove the MODD Holder Assy.
11. Unscrew four screws (
7
10
).
12. Remove the MODD.
Note
There are two types of MODD for the spare parts. The folding method of CB24A (or CB24N) cable is
different between the case of using the old MODD (U0052ZA) and the case of using the new one
(2187012). For more details regarding the folding cable, refer to 6–6–4 on page 6–263.
