Page #278 background imageLoading...
Page #278 background image
LOGIQ 400 SERVICE MANUALGE MEDICAL SYSTEMS
2127661
RENEWAL PARTS
6–148
REV 9
6–2–50 Keyboard Assy (FRU No. 401), Keyboard Cover (FRU No. 402), Key Sheet (FRU No. 403)
Time Required
30 Minutes
Tool Required
Screwdriver
Hexagonal Wrench
Procedure
Refer to ILLUSTRATION 6–73 on page 6–149.
1. Turn OFF the system.
2. Remove six encoder knobs and eight TGC knobs. Refer to ILLUSTRATION 6–79 on page 6–159.
3. Remove the Keyboard Panel Assy. Refer to 6–2–49 on page 6–147.
4. Unscrew nine screws (
1
9
) to remove two metal plates.
5. Unscrew ten screws (
10
19
).
6. Remove the Keyboard Cover (FRU 402).
7. Unscrew twelve screws (
20
31
).
8. Remove the Key Sheet (FRU 403) out of the Keyboard Assy or the Keyboard Panel2 Assy (FRU 401).
Note
The color of the Key Sheet for the LOGIQ 400CL is different from the other color monitor assy. Use
the proper FRU when replacing the Key Sheet for the LOGIQ 400CL.
