GE LOGIQ 400 Service Manual

GE MEDICAL SYSTEMS
2127661
LOGIQ 400 SERVICE MANUAL
TM
8–78 OPTIONS
REV 5
8–7 FOOT SWITCH INSTALLATION
8–7–1 Foreword
This section describes the installation of the Foot Switch option for LOGIQ 400.
8–7–2 Tools Required
Standard field Service Tool kit
8–7–3 Time Required
Approx. 15 Minutes
8–7–4 Parts Required
ITEM PART NAME QTY PART # REMARKS
1. Foot Switch 1 P9509NB
8–7–5 Functional Check–out
READ and UNDERSTAND these instructions thoroughly before proceeding with the installation. Perform each step in
sequence and check it off when completed. If a problem occurs after completion, go back through the procedure and
check for implementation errors before contacting your Ultrasound Region Engineer.
CAUTION
Possible operational damage. Failure to strictly follow ESD (Electrostatic Discharge) precau-
tions during this upgrade may cause constant or intermittent operational abnormalities.
Strictly follow all precautions.
Check each step as it is completed.
Perform functional checks to verify that the system is functioning properly. Refer to Chapter 4, Functional Checks.
