GE LOGIQ 400 Service Manual

2127661
LOGIQ 400 SERVICE MANUALGE MEDICAL SYSTEMS

RENEWAL PARTS
6–222
REV 9
6–2–89 SSR Unit (FRU No. 705)
Time Required
30 Minutes
Tool Required
Screwdriver
Procedure
Refer to ILLUSTRATION 6–124 on page 6–223.
1. Turn OFF the system and unplug the main power cord.
2. Remove the Power Control Unit (FRU 704). Refer to 6–2–88 on page 6–220.
3. Unscrew two screws (
1
and
2
).
4. Pull the SSR Unit outwards.
5. Unscrew eight screws (
3
–
10
) to remove eight wires.
6. Pull four crimp contacts (
11
–
14
) out of the SSR Unit.
7. Remove the SSR Unit.
