LOGIQ 400 SERVICE MANUALGE MEDICAL SYSTEMS
2127661
RENEWAL PARTS
6–156
REV 9
6–2–55 Keyboard Cover Assy (FRU No. 451), SW PWB (FRU No. 462),
Rubber Key (FRU No. 452, 453, 454, and 455 )
Time Required
30 Minutes
Tool Required
Screwdriver
Hexagonal Wrench
Procedure
Refer to ILLUSTRATION 6–78 on page 6–157.
1. Turn OFF the system.
2. Remove six encoder knobs and eight TGC knobs. Refer to ILLUSTRATION 6–79 on page 6–159.
3. Remove the Keyboard Panel Assy. Refer to ILLUSTRATION 6–77 on page 6–155.
4. Unscrew twenty seven screws (
1
27
).
4. Remove nine conectors (
28
36
).
6. Remove the SW PWD Assy (FRU 462).
7. Remove the Rubber Key Assy (FRU 452, 453, 454 and 455).
Note
The color of the Key Sheet for the LOGIQ 400CL is different from the other color monitor assy. Use
the proper FRU when replacing the Key Sheet for the LOGIQ 400CL.
Note
There are 4 type of Rubber key AN Assy depend on the support Language. Use the proper Rubber
key AN Assy for using the Language.
