GE LOGIQ 400 Service Manual

GE MEDICAL SYSTEMS
2127661
LOGIQ 400 SERVICE MANUAL

RENEWAL PARTS
6–220
REV 9
6–2–88 Power Control Unit (FRU No. 704)
Time Required
30 Minutes
Tool Required
Screwdriver
Procedure
Refer to ILLUSTRATION 6–123 on page 6–221.
1. Turn OFF the system and unplug the main power cord.
2. Remove the Side Cover Left (FRU 301). Refer to 6–2–31 on page 6–127.
3. Remove the Left PS Cover. Refer to 6–2–87 on page 6–218.
4. Unscrew two screws (
1
and
2
).
5. Disconnect eight connectors on the Power Control Unit (
3
and
10
).
6. Remove the Power Control Unit.
