GE MEDICAL SYSTEMS
2127661
LOGIQ 400 SERVICE MANUAL
TM
8–36 OPTIONS
REV 5
8–3–9 Setting Parameters of UP–2950 Series Printers (Continued)
20. Press the UP arrow key twice and then the RIGHT arrow key once to display the “PRINTER SETUP” menu.
21. Press the DOWN arrow key five times to display the “FUNCTION SETUP” menu. Refer to ILLUSTRATION 8–38.
FUNCTION :
PRESS[>]
SETUP MENU OF PRINTER (h)
ILLUSTRATION 8–38
22. Press the RIGHT arrow key to display the FUNCTION SETUP sub–menu.
23. Press the DOWN arrow key twice to display the “IMMED. CAP” menu. Refer to ILLUSTRATION 8–39.
IMMED.CAP:
off/ON
SETUP MENU OF PRINTER (i)
ILLUSTRATION 8–39
24. Make sure that the IMMED. CAP is set to “ON” (“off/ON” is displayed on the LCD when the IMMED. CAP is set to
ON). Refer to ILLUSTRATION 8–39.
Otherwise, set the IMMED. CAP to “ON” using the LEFT arrow or RIGHT arrow key.
25. Press the MENU key to exit the setup menu.
8–3–10 Operational Check–out
1. Plug in the system and power the system ON.
2. Power the Color Video Printer ON.
3. Press New Patient key when the PATIENT ENTRY MENU is displayed on the CRT monitor screen of
LOGIQ 400.
4. Set the system so that the Color Video Printer can work by the key operation on the console.
The following steps (step a. to o.) indicates one example when you set the Color Video Printer control with the
following conditions:
I. Select UP–1850 color video printer.
II. Select Single memory as type of color printer memory.
III. Use RGB–Sync color printer signal.
IV. Connect RS232C cable with ”port A” located at rear panel of LOGIQ 400.
V. Set that pressing Record1 key causes the color video printer to print image including color data.
(Image including only B/W data is printed by B/W video printer.)
To Next Page
