2127661
LOGIQ 400 SERVICE MANUALGE MEDICAL SYSTEMS
RENEWAL PARTS
6–238
REV 9
6–2–97 Power Inlet Unit2 (FRU No. 754 for 115V, FRU No. 755 for 220V)
Time Required
15 Minutes
Tool Required
Screwdriver
Procedure
Refer to ILLUSTRATION 6–133 on page 6–239.
1. Turn OFF the system and unplug the main power cord.
2. Remove the Rear Cover (FRU 303). Refer to 6–2–33 on page 6–129.
3. Unscrew six screws (
1
6
).
4. Pull the Power Inlet Unit out.
5. Disconnect one connector (
7
) .
6. Unscrew two screws (
8
and
9
) to remove two FG wires.
7. Remove the Power Inlet Unit2.
