GE LOGIQ 400 Service Manual

GE MEDICAL SYSTEMS
2127661
LOGIQ 400 SERVICE MANUAL

RENEWAL PARTS
6–214
REV 9
6–2–85 High Voltage Assy (FRU No. 701)
Time Required
30 Minutes
Tool Required
Screwdriver
Procedure
Refer to ILLUSTRATION 6–120 on page 6–215.
1. Turn OFF the system and unplug the main power cord.
2. Remove the Front Base Cover (FRU 305). Refer to 6–2–35 on page 6–131.
3. Remove the Side Cover Right (FRU 302). Refer to 6–2–32 on page 6–128.
4. Unscrew four screws (
1
–
4
).
5. Remove the PS Cover Right.
6. Unscrew two screws (
5
and
6
).
7. Disconnect five connectors (
7
–
11
).
8. Pull the High Voltage Assy out.
9. Disconnect the HV Fan Cable (
12
).
10. Remove the High Voltage Assy.
