6–2–21 Monitor15 Assy (FRU No. 170)
Time Required
0.25 Hours
Tool Required
Screwdriver
Hexagonal Wrench
Procedure
WARNING!
PERSONAL INJURY HAZARD. VIDEO MONITOR SUPPORT ARM IS SPRING LOADED. RE-
LEASING ARM WHEN MONITOR IS NOT INSTALLED WILL CAUSE SUDDEN UPWARD MOVE-
MENT. KEEP YOUR HEAD AND BODY AWAY FROM ABOVE VIDEO MONITOR SUPPORT ARM.
Refer to ILLUSTRATION 6–40 on page 6–105.
1. Turn OFF the system.
2. Remove the CRT Filter. Refer to ILLUSTRATION 6–35 on page 6–97.
3. Unscrew four hexagonal screws (
1
–
4
) located beneath the horizontal part of the Neck Assy.
4. Remove the cover located at the bottom of the Neck Assy.
5. Unscrew two screws (
5
and
6
) and remove the plate fixing the cables.
6. Disconnect the four connectors (
7
–
10
).
7. Remove the screw cap located at position (
11
).
8. Loosen one screw (
11
) and pull the Monitor15 Assy upwards.
Note
The Monitor 15 Assy (FRU170) does not include the CRT Filter15 Set (FRU176).
