6–2–71 Probe CONN 1 Assy (FRU No. 517) or DCON Assy (FRU No. 518)
Time Required
30 Minutes
Tool Required
Screwdriver
Procedure
Refer to ILLUSTRATION 6–97 on page 6–181.
1. Turn OFF the system.
2. Remove the Probe CONN Set Assy (FRU 512/513). Refer to 6–2–68 on page 6–176.
3. Remove the PRAG Assy (FRU 519). Refer to 6–2–72 on page 6–182.
4. Unscrew eight screws (
1
–
8
).
5. Remove the connector frame.
6. Unscrew twelve screws (
9
–
20
).
7. Unscrew three screws (
21
–
23
).
8. Unscrew two studs (
24
and
25
).
9. Remove the Probe CONN 1 Assy or DCON Assy.
