USB Device Server Option Type M19 (D3BC-28, 29)
SM 2-115 D255/D256/M281/M282
Installation
What Do the LED Indicators Mean?
When this option is properly installed and recognized by the main machine, the LED indicators
light up under the following conditions.
No. LED Color Lights Up When:
1 Green and Yellow 1000BASE-T operates.
2 Green 10BASE-T operates.
3 Yellow 100BASE-TX operates.
⇒
Rev. 08/09/2016
