Paper Feed Unit
D255/D256/M281/M282 4-112 SM
4. Remove the paper feed roller [A] from the feed roller holder [B]. (hook×1)
5. Remove the pickup roller [A]. (hook×1)
4.19.2 SEPARATION ROLLER
1. Remove the paper feed tray [A] by pulling it out.
2. Remove the separation roller holder [A].
