Exterior Covers (MP 501/601)
D255/D256/M281/M282 4-38 SM
4.6.14 PAPER EXIT COVER
1. Remove the rear center stay. (page 4-36)
2. Remove the two screws from the paper exit cover [A].
3. Remove the paper exit cover [A] from the right side. (hook×1)
 Be careful not to damage the hook at the rear of the paper exit cover when you remove or
install the paper exit cover.
To Next Page
