Test Pattern Printing
SM 5-65 D255/D256/M281/M282
System
Maintenance
5.10.2 SP 5300/5310
1. Enter the SP mode and select SP2-109-003 (Test Pattern).
2. Enter the number for the test pattern that you want to print -> Press [OK].
SP2-109-003 (Test Pattern)
No. Pattern No. Pattern
0 None 13 Independent Pattern (4dot)
1 Vertical Line (1 dot) 14 Trimming Area
2 Vertical Line (2 dot) 15 Hound's Tooth Check (Horizontal)
3 Horizontal Line (1 dot) 16 Hound's Tooth Check (Vertical)
4 Horizontal Line (2 dot) 17 Black Band (Horizontal)
5 Grid Vertical Line 18 Black Band (Vertical)
6 Grid Horizontal Line 19 Checker Flag Pattern
7 Grid Pattern Small 20 Grayscale (Vertical)
8 Grid Pattern Large 21 Grayscale (Horizontal)
9 Argyle Pattern Small 22 Two Beam Density Pattern
10 Argyle Pattern Large 23 Full Dot Pattern
11 Independent Pattern (1dot) 24 All White Pattern
12 Independent Pattern (2dot)
3. To change the density of the test pattern, select the density with SP2-109-006.
 If select "0" with SP2-109-006, the color adjusted so will not show up in the test
pattern.
4. Enter SP5-990-001, and then press [EXECUTE] to start printing the test pattern.
5. Check the test pattern.
6. Exit SP mode.
