Service Program Tables
D255/D256 FAX OPTION 58 SM
4. SERVICE TABLES
4.1 SERVICE PROGRAM TABLES
4.1.1 SP1-XXX (BIT SWITCHES)
1 Mode No. Function
101 System Switch
001 – 032 00 – 1F Change the bit switches for system settings for the
fax option
Refer to page 65 "Bit Switches - 1": "System
Switches".
102 Ifax Switch
001 – 016 00 – 0F Change the bit switches for internet fax settings for
the fax option
Refer to page 80 "Bit Switches - 2": "I-Fax Switches".
103 Printer Switch
001 – 016 00 – 0F Change the bit switches for printer settings for the fax
option
Refer to page 80 "Bit Switches - 2": "Printer
Switches".
104 Communication Switch
001 – 032 00 – 1F Change the bit switches for communication settings
for the fax option
Refer to page 95 "Bit Switches - 3": "Communication
Switches".
105 G3-1 Switch
001 – 016 00 – 0F Change the bit switches for the protocol settings of
the standard G3 board
Refer to page 105 "Bit Switches - 4": "G3 Switches".
111 IP fax Switch
