Service Call 490-491
SM 6-19 D255/D256/M281/M282
Troubleshooting
6.5 SERVICE CALL 490-491
6.5.1 SC400 (ENGINE: IMAGING 3: AROUND THE DRUM)
SC No. Type Error Name/Error Condition/Major Cause/Solution
SC490-00 D Toner Density Sensor Error
The sensor output value is 930 or more continuously for 5
seconds.
 Toner density sensor defective
 Toner motor defective
 Connect-Left PCB defective
 IOB defective
 Toner density sensor defective
1. Reconnect the following connectors.
 Toner Density Sensor – Drum PCB connector
 Drum PCB – Drum Connection PCB connector
 Drum Connection PCB – Connect-Left PCB
connector
 Connect-Left PCB – IOB connector
2. If the connector is broken, shorted, or grounded,
replace the connector.
3. Check that the gears and rollers of the development
unit are not damaged and rotate smoothly.
4. Replace the development unit.
