Test Pattern Printing
SM 5-63 D255/D256/M281/M282
Maintenance
5.10 TEST PATTERN PRINTING
Printing Test pattern: SP2-109
Some of these test patterns are used for copy image adjustments but most are used primarily for
design testing.
 Do not operate the machine until the test pattern is printed out completely. Otherwise, SC
will occur.
5.10.1 MP 501/601
1. Enter the SP mode and select SP2-109-003 (Pattern Selection).
2. Select the test pattern for print from the list then press [OK].
3. To change the density of the test pattern, select the density with SP2-109-006, then
press [#].
 If select "0" with SP2-109-006, the color adjusted so will not show up in the test
pattern.
4. To print, touch [Copy Window], then set settings within the following window for test
print (paper size etc…).
5. Press [Start] to start test print.
6. After checking test pattern, press [SP Mode] to return to SP mode display.
7. Reset all settings to the default values (SP2-109-003, SP2-109-006).
8. Exit SP mode.
No. Pattern No. Pattern
0 None 13 Independent Pattern (4dot)
1 Vertical Line (1 dot) 14 Trimming Area
2 Vertical Line (2 dot) 15 Hound's Tooth Check (Horizontal)
3 Horizontal Line (1 dot) 16 Hound's Tooth Check (Vertical)
4 Horizontal Line (2 dot) 17 Black Band (Horizontal)
5 Grid Vertical Line 18 Black Band (Vertical)
6 Grid Horizontal Line 19 Checker Flag Pattern
7 Grid Pattern Small 20 Grayscale (Vertical)
To Next Page
