Product Overview
SM 7-13 D255/D256/M281/M282
Descriptions
SP 5300/5310 Others
No. Name No. Name
1 Fusing thermostat 1 (End) 8 Transport clutch
2 Fusing thermostat 2 (Center) 9 Bypass solenoid
3 Fusing lamp 1 10 Duplex clutch
4 Fusing lamp 2 11 Control panel
5 Development clutch 12 Inverter solenoid
6 Registration clutch 13
Drum heater PCB (Asia and
Chinese Only)
7 Paper feed clutch 14 Quenching lamp
To Next Page
