Drum Unit
D255/D256/M281/M282 7-18 SM
7.5.2 CLEANING UNIT
No. Name No. Name
1 Drum 5 Scraper
2 Cleaning blade 6 Drum frame
3 Cleaning roller 7 Waste toner removal coil (drum coil)
4 Control roller 8 Quenching lamp
