Drum Unit
SM 4-93 D255/D256/M281/M282
Replacement
and Adjustment
4.14.2 CHARGE ROLLER
1. Open the front cover.
MP 501/601: Push the button [A] and open the front cover [B].
SP 5300/5310: Open the upper cover [A], and then open the front cover [B].
2. Release the lock lever [A] by rotating it towards you, and then remove the toner
cartridge [B].
