Exterior Covers (SP 5300/5310)
SM 4-47 D255/D256/M281/M282
Replacement
and Adjustment
4.7 EXTERIOR COVERS (SP 5300/5310)
4.7.1 UPPER COVER
1. Remove the controller cover. (page 4-67)
2. Open the upper cover [A].
3. Remove the two screws from the upper cover [A].
 The screw [B] is a sems screw. The screw [C] is a tapping screw. Be careful not use
the wrong screws when installing the upper cover.
4. Remove the screw from the rear side of the upper cover [A].
