Trilithic 180 DSP User Manual

www.trilithic.com
Page II-62
180 DSP Operation Manual
Signal Level Meter
Open an Existing Limit Set
Perform the following steps to open an existing limit set:
1. Select the File softkey.
2. From the File pop-up menu, select
the Open button as shown in the
image to the right.
3. The Limit Set window will be
displayed as shown below (left).
4. Select the name of the limit set that
you would like to open.
5. The selected limit set and its
thresholds are displayed as shown below (right). Use the up/down arrow buttons to
highlight specic thresholds for editing or removal.
6. The new limit set will be displayed
as shown in the image to the right.
Use the up/down arrow buttons to
highlight specic limits for editing or
removal.
