Trilithic 180 DSP User Manual

www.trilithic.com
Page IV-77
180 DSP Operation Manual
Signal Level Meter
Select the Open button from the Limit Set
pop-up menu and the Limit Set window will
be displayed as shown in the image to the
right.
From the Limit Set window, select the name
of the limit set to use for the tilt measurement.
After selecting the limit set, the Plan Tilt
screen will be displayed again.
Opening a Limit Set
Select the Limit Set softkey as shown in the
image to the right to select the limit set to use
for the tilt measurement.
The Limit Set window will be bypassed if there is only one
limit set to choose from.
