Trilithic 180 DSP User Manual

www.trilithic.com
Page VI-5
180 DSP Operation Manual
Signal Level Meter
*In-service, non-scrambled standard channels only
Minimum Input
Level for Full
Range
+10 dBmV
Dynamic Range 50 dB
Resolution < 0.5 dB
Carrier-to-Noise Measurement
Max Number of
Carriers
14 (dependent on favorite channel setup)
High/Low Delta
Resolution
0.1 dB
Scan Video, audio, pilot, and digital carriers
Tilt Measurement
*In-service, non-scrambled standard channels only
Minimum Input
Level
0 dBmV
Range 0% to 5%
Resolution 0.1%
Accuracy ±0.5%
Analog & Digital HUM Measurement (OPTIONAL)
