Trilithic 180 DSP User Manual

www.trilithic.com
Page IV-145
180 DSP Operation Manual
Signal Level Meter
Velocity of Propagation Adjustment
The velocity of propagation can be adjusted
from 60.0 to 99.0%. Highlight the velocity of
propagation eld as shown in the image to
the right and then use either of the following
methods to change the value:
• Use the up/down arrow buttons to
change the reference level in 0.1%
increments.
• Press the Enter button and use the
Virtual Keyboard to directly enter the
velocity of propagation as shown in the
image to the right.
• Press the Preset softkey to select
one of the following preset velocity of
propagation settings:
• RG-59 Mini VoP 83.0%
• RG-59 VoP 85.0%
• RG-6 VoP 85.0%
• RG-11 VoP 85.0%
• Semi-Rigid VoP 87.0%
• Hardline VoP 87.0%
