Trilithic 180 DSP User Manual

www.trilithic.com
Page IV-19
180 DSP Operation Manual
Signal Level Meter
Digital Channel Measurement
When a digital channel is selected, the Level
screen will display the following information
based on the settings of the current channel
plan:
• Reference Level (adjustable)
• Vertical Scale (adjustable)
• Channel Number (adjustable)
• Channel Name
• Digital Video Frequency (adjustable)
• Channel Bandwidth (adjustable)
• Modulation Type (adjustable)
• Channel Standard (adjustable)
• Symbol Rate (adjustable)
• Display Type (adjustable)
