www.trilithic.com
Page II-99
180 DSP Operation Manual
Signal Level Meter
Save to USB Flash Drive
This function is used primarily for remote troubleshooting with the Trilithic Applications
Support Department. This le can be emailed to Trilithic for advanced troubleshooting.
Perform the following steps to save the 180 DSP log le to a USB ash drive:
1. Insert a USB ash drive into the
USB Port of the 180 DSP.
2. Press the Function button and
select the Activate USB Power
function as shown in the image to
the right.
3. The power to the USB ash drive
is activated and the drive is now
mounted to the le system as
shown in the image to the right.
The 180 DSP is now capable of
transferring les to and from the
USB ash drive.
4. Select the Save Log softkey.
5. The Message Bar will indicate a
successful save to the ash drive
by displaying the text
“-> /media/sda1/slm360log.txt”
as shown in the image to the right.
