Trilithic 180 DSP User Manual

www.trilithic.com
Page V-9
180 DSP Operation Manual
Signal Level Meter
CW Signal Settings
The settings shown in the following sections can be adjusted when the Modulation is set to
CW.
Amplitude Adjustment
The amplitude level can be adjusted from
10 to 40 dBmV. Highlight the Amplitude
eld as shown in the image to the right
and then use either of the following
methods to change the amplitude level:
• Use the up/down arrow buttons
to change the amplitude level in 1
dBmV increments.
• Press the Enter button and use the
Virtual Keyboard to directly enter
the amplitude level as shown in the
image to the right.
