180 DSP Operation Manual
Signal Level Meter
Modulation
CW, 16 QAM, 32 QAM, 64 QAM, 128 QAM, 256 QAM, OFDM
(4K/8K) (dependent on RF board)
OFDM Subcarrier
Modulation
(1.2 GHz RF board
only)
16 to 4096 QAM, PLC Configurable
Frequency Range 5 to 85 MHz
Source Width
CW: 50 kHz
QAM: 6 MHz
OFDM: 6 to 24 MHz (1.2 GHz RF board only)
Amplitude
CW: Adjustable from 10 to 55 dBmV
QAM: Adjustable from 10 to 45 dBmV
OFDM: Adjustable from 10 to 40 dBmV (1.2 GHz RF board only)
QAM Symbol
Rates
0.64, 1.28, 2.56, 5.12 MSPS
QAM Error Rates
BER: Adjustable from 0 to 1.00E-2
MER: > 38 dB
CW Source
Accuracy
±2 dB
Source Generator (OPTIONAL)

Trilithic 180 DSP Specifications

General

Brand	Trilithic
Model	180 DSP
Category	Measuring Instruments
Language	English
