www.trilithic.com

Page IV-137

180 DSP Operation Manual

Signal Level Meter

Removing a Limit Set

Select the Limit Set softkey as shown in the

image to the right to remove the limits set for

the cable modem measurement.

Select the Remove button from the Limit Set

pop-up menu and the pass/fail results will no

longer be displayed as shown in the image to

the right.
