Page II-104
180 DSP Operation Manual
Signal Level Meter
Calibrate Touchscreen
Perform the following steps to calibrate the 180 DSP touchscreen:
1. Select the Calibrate softkey.
2. The Calibrate Touchscreen window
will be displayed as shown to the right.
3. Select the Yes button to calibrate
the touchscreen or select the No
button to exit without calibrating the
touchscreen.
4. To calibrate the touchscreen, select the cross that appears on the screen with the
included stylus. During the calibration, the Message Bar at the bottom of the screen will
prompt you through selecting multiple points on the screen.
5. After you have selected the last cross the Message bar will display the text
“Calibration Success” to indicate that the calibration has been completed successfully.
