Page V-12
180 DSP Operation Manual
Signal Level Meter
Symbol Rate Adjustment
The symbol rate can be adjusted from
0.64 to 5.12 MSPS. Highlight the Symbol
Rate eld as shown in the image to the
right and then use the up/down arrow
buttons to choose between symbol rates
of 0.64, 1.28, 2.56 or 5.12 MSPS.
Bit Error Rate Adjustment
The bit error rate (BER) can be adjusted
from 0 to 1.00E-2. Highlight the BER
eld as shown in the image to the right
and then use the up/down arrow buttons
adjust the BER in 1.00E-1 increments.
