Trilithic 180 DSP User Manual

www.trilithic.com
Page III-17
180 DSP Operation Manual
Signal Level Meter
Using Autotests
Chapter 4
Overview
The Autotest menu can include any number
of Autotest apps that are congured using the
ViewPoint WFM Module. The image shown to
the right displays four different Autotest apps
Default, Home Check, Commercial, and
Dormitory that were congured using the
ViewPoint WFM Module.
Select any of the Autotest apps as shown in
the image to the right to execute an Autotest
on the 180 DSP.
If a job hasn’t been opened, the Job
Management window will be displayed.
Choose the job that you would like to perform
that Autotest on.
If a channel plan is not open, the Channel
Plan window will be displayed. Choose the
channel plan you want to use.
The Autotest screen will be displayed as
shown in the image to the right. This screen
allows you execute autotests at multiple
locations for each job on the 180 DSP.
The Autotest screen displays the Autotest
Name, Job, Channel Plan, and Tech ID above
the test locations.
See the ViewPoint WFM Module Operation Manual for more
information on how to create Autotest Apps and congure
Locations, Channel Plans, and Limit Sets for Autotesting.
