www.trilithic.com
Page IV-127
180 DSP Operation Manual
Signal Level Meter
Network Test Suite
Chapter 6
Overview
The Network Tests screen will be displayed
as shown in the image to the right. This
screen displays a measurement bar graph
speciîš¿c to the type of measurement along
with relevant measurement values.
The Network Test Suite is a standard feature
of the 180 DSP that is used to perform
network tests and includes Ping, VoIP,
Throughput, and Traceroute tests. Select the
Net Tests icon as shown in the image to the
right to perform network tests using the 180
DSP.
If you are not connected to the network,
the meter will connect using your preferred
method.
