Page I-38
180 DSP Operation Manual
Signal Level Meter
Perform the following steps to connect using the Ethernet connection:
1. Connect an Ethernet cable to the
Ethernet port of the 180 DSP.
2. Select the Ethernet connection
button from the Network Manager
window as shown in the image to
the right.
Ethernet Connection
3. If the Prompt User option is set
to Yes from within the Ethernet
Settings option of the Setup
menu, the Ethernet Settings
window will appear as shown in
the image to the right. Adjust the
Ethernet settings as desired and
then select the Login button.
If the Prompt User option is set to No from within the Ethernet
Settings option of the Setup menu, the Ethernet Settings
window will not appear. If so, proceed to Step 4.
