Trilithic 180 DSP User Manual

www.trilithic.com
Page IV-147
180 DSP Operation Manual
Signal Level Meter
Starting and Stopping the Measurement
The FDR measurement can be started and
stopped using the On and Off softkeys.
When the source is deactivated, the
measurement screen will appear empty as
shown in the image to the right. Also, if you
exit the FDR screen at any time, the source
output will automatically be deactivated.
When the source is activated and a
reection is found, the measurement screen
will appear as shown here.
