www.trilithic.com
Page I-9
180 DSP Operation Manual
Signal Level Meter
What is the 180 DSP?
Overview
• Tailored to Simplify Installation and
Troubleshooting of RF Signals
• 1.25 GHz RF Measurement Range with
Channel Plan Auto Discovery
• Intuitive, Color Touchscreen with Simple Pass/
Fail Indicators Reduces Installer Entry Errors
and Improves Decision Making
• Multiple Tests in a Single Autotest App Provide
a Convenient Way to Standardize Tech
Processes & Procedures
• Powerful Troubleshooting Tools to Improve the
Overall Health of the System
• High-Intensity LED Flashlight Designed for Working in Cramped, Dark Spaces
The Standardization Solution
Trilithic’s 180 DSP™ is a basic signal level meter specically tailored for installation and
troubleshooting of RF signals. Featuring fast measurements and powerful troubleshooting
tools the 180 DSP comes equipped with all the tests an installer needs to measure both
Analog and Digital signals and ensure the highest quality installation—and includes a price
point that makes it feasible for system operators to outt their entire eet.
Tailored for the challenges faced by installers, contractors, and service techs, this meter
helps simplify decision making and streamlines standard processes and procedures, while
improving tech efîš¿ciencies and the overall health of the entire system.
Next-Gen Features
The 180 DSP features an intuitive, color touchscreen interface, simple pass/fail indicators,
and autotest apps to streamline basic RF installation and make the installer’s job easier.
Everything about this next-gen meter was built with the technician in mind—from the
quickest charge time of any signal level meter, to its unique, built-in LED ashlight and glow
in the dark keypad for those dark, cramped spaces.
